It is mainly used for tensile, compression, bending, shearing, tearing, stripping and other mechanical properties testing of various
materials and products, and can achieve combined command control ofstress, strain, speed and so on. According to GB, ISO, ASTM,
DIN, JIS and other test standards, automatically obtain the maximum test force, elastic modulus, yield strength, extension strength,
tensile and compressive strength, various elongation stresses, elongation and other parameters.

Product Detail

Features:

1. Exquisite design, ergonomic working platform, easy to operate;

2. Arc tooth synchronous belt deceleration system: with high efficiency, long life, low noise, maintenance-free advantages;

3.High precision grinding ball screw loading: smooth loading, no noise, long service life, stable, reliable and energy saving;

4.The guide rod structure is adopted, and the moving beam runs up and down without bias, with high coaxiality and good rigidity;

5. Adopt the latest generation of controller based on DSCC chip developed by the company, with good repeatability and high reliability;

6. User interface: simple and reliable human-computer interaction interface and data processing interface to complete different

experimental requirements selected by users;

7. Open data structure: both result parameters and process data are allowed to be randomly called by users, which is very conve-

nient for detection, scientific research and teaching;

8. Users can edit test standards, test plans and test reports by themselves, data can be imported into WORD,EXCEL, convenient for

users to post-processing, automatically generate test reports,and can print test reports and curves at any time;

9. Avariety of protection measures: such as electronic limit protection,over current, over voltage and other power links ofvarious electri-

cal protection, software internal force value overload, displacement over limit protection, mechanical forced safety limit protection.
